LunIR

LunIR (Lunar InfraRed Imaging, formerly known as SkyFire) is a nanosatellite spacecraft launched to the Moon collecting surface spectroscopy and thermography. It was launched as a secondary payload on the Artemis 1 mission on 16 November 2022.[1][2]

LunIR
The LunIR CubeSat, which will characterize and collect lunar surface data.
NamesSkyFire
Mission typeTechnology demonstrator, reconnaissance
OperatorLockheed Martin Space
COSPAR ID2022-156K
SATCAT no.57686
Mission duration1 year, 6 months and 20 days (in progress)
Spacecraft properties
SpacecraftCubeSat
Spacecraft type6U CubeSat
BusTyvak Nano-Satellite Systems
ManufacturerLockheed Martin Space
Launch mass14 kg (31 lb)
Dimensions10 cm × 20 cm × 30 cm
Start of mission
Launch date16 November 2022, 06:47:44 UTC[1]
RocketSLS Block 1
Launch siteKSC, LC-39B
ContractorNASA
Flyby of Moon
NextSTEP program


Mission

LunIR is a technology demonstration mission funded by NASA that uses a low-cost 6U CubeSat spacecraft. LunIR will perform a lunar flyby, collecting spectroscopy and thermography for surface characterization, remote sensing, and site selection.[3] The spacecraft includes two deployable solar panels and will have a total mass of about 14 kg (31 lb).

LunIR was selected in April 2015 by NASA's NextSTEP program (Next Space Technologies for Exploration Partnerships) and awarded a contract to Lockheed Martin Space worth US$1.4 million for further development.[4][5][6]

LunIR will communicate with Earth via ground stations operated by Kongsberg Satellite Services. LunIR will use 13-meter-diameter radio antennas located in Punta Arenas, Chile; Svalbard, Norway; and Troll station, Antarctica.[7][8]

Launch

LunIR was launched as one of ten CubeSats as a secondary payload on the maiden flight of the Space Launch System, Artemis 1.[2]

Propulsion

LunIR will demonstrate a low thrust electric propulsion technology called electrospray propulsion to lower the spacecraft's orbit for additional science and technology mission objectives.[9]

See also
The 10 CubeSats flying in the Artemis 1 mission
  • Near-Earth Asteroid Scout by NASA was a solar sail spacecraft that was planned to encounter a near-Earth asteroid (mission failure)
  • BioSentinel is an astrobiology mission
  • LunIR by Lockheed Martin Space
  • Lunar IceCube, by the Morehead State University
  • CubeSat for Solar Particles (CuSP)
  • Lunar Polar Hydrogen Mapper (LunaH-Map), designed by the Arizona State University
  • EQUULEUS, submitted by JAXA and the University of Tokyo
  • OMOTENASHI, submitted by JAXA, was a lunar lander (mission failure)
  • ArgoMoon, designed by Argotec and coordinated by Italian Space Agency (ASI)
  • Team Miles, by Fluid and Reason LLC, Tampa, Florida
The three CubeSat missions removed from Artemis 1
  • Lunar Flashlight will map exposed water ice on the Moon
  • Cislunar Explorers, Cornell University, Ithaca, New York
  • Earth Escape Explorer (CU-E3), University of Colorado Boulder
